★主要技術參數（Technical parameters）：
1、砂輪主軸徑向跳動:0.008mm，傳動羅拉徑向跳動:0.008mm
Vertical vibration of stone or driving roller main axle: 0.008 mm
2、磨礪后膠輥的徑向跳動:0.015mm(排除膠輥本身間隙條件下)
Vertical vibration of rubber roller after processing:0.015mm
(excluding clearance of rubber roller itself)
3、磨礪后膠輥的兩端直徑差:0.015mm(排除膠輥本身間隙條件下)
Diameter difference between of two ends of rubber roller after
processing:0.015 mm(excluding clearance of rubber roller itself)
4、磨礪后膠輥的表面粗糙度:Ra0.2～0.8mm(精磨)
Surface roughness of rubber roller after processing: Ra 0.2~0.8um
5、磨礪速度(Output): 800～1000只/班×2（pcs/8h）
6、外形尺寸(package)：長(L)×寬(W)×高(H)=（145×100×160）cm3
7、機器毛凈重(G/N weight)：750/680kg
★性能特征（Characteristics）：
1、雙工位精度磨礪，效率翻倍。
The double location accuracy efforts, double the efficiency.
2、磨礪精度高、磨礪性能穩定。
High precision hone honed stable performance
3、適應對粗紗、細紗膠輥進行快速磨礪。
To adapt to the roving yarn spinning roller mill fast
4、雙無中心夾具：確保羅拉軸承與膠輥的同心度。
Double no center fixture: make sure the roller bearing and roller concentricity.
雙夾具與雙砂輪
選配檢測表座
